YWF500 External rotor fan

Size: Φ500mm
Motor wires: 100% pure copper motor wires
Bearing: Ball
Technical characteristics

Item code: YWF500 External rotor fan

Housing: Iron or aluminium alloy, Painted Blue

Impeller: Thermoplastic PBT, UL94V-0

Lead Wire: UL 1007 AWG#22

Termination: Lead wire, no connector

Operating Temperature: -30℃ to +60℃ for Ball Type


Performance Parameter
Model Rated Voltage Frequency Rated Current Imput power W Rated Speed Air Flow Poles Capacitance Noise Level
V  AC Hz Amp RPM M3/hr μF/V dBA
YWF500-2 200-240 50/60 1.9/2.3 420/500 1320/1450 6500/6800 4 6 69/70
YWF500-3 380-420 50/60 0.9/1.0 420/500 1350/1500 6500/6800 4 / 69/70
YWF500-6 200-240 50/60 1.1/1.35 220/250 900/1020 4320/4800 6 4 65/66
YWF500-7 380-420 50/60 0.6/0.62 220/250 900/1100 4320/4800 6 / 65/66
