EC 12025

Size: 120*120*25mm
Motor wires: 100% pure copper motor wires
Bearing: Ball or Sleeve
Weight: 140g
Safety: Impedance Protected
Technical characteristics

Item code: EC 12025

Housing: Thermoplastic PBT, UL94V-0

Impeller: Thermoplastic PBT, UL94V-0

Lead Wire: UL 1007 AWG#24

Termination: Lead wire, no connector

Operating Temperature: -10℃ to +70℃ for Sleeve Type
                                        -20℃ to +80℃ for Ball Type


Performance Parameter
Model Bearing System Rated Voltage Freq. Operation Voltage Rated Current Rated Power Rated Speed Air Flow Air Pressure Noise Level
Ball Sleeve V AC Hz V AC Amp Watt RPM CFM mmH2O dBA
AM12025HEC 115/230 50/60 98-264 0.08 7 2600 100.2 4.2 38
AM12025MEC 0.06 4 2200 85.5 3.0 33
AM12025LEC 0.05 3 1800 68.6 2.1 28
