| Size: | 40*40*10mm |
| Motor: | DC brushless fan motor |
| Bearing: | Ball, Sleeve or Hydraulic |
| Weight: | 17g |
| No. of Pole: | 4 Poles |
| Rotating Direction: | Counter-Clockwise |
| Optional Function: | 1.Lock Protection |
| 2.Polarity Protection. | |
| 3.Waterproof Level |
Item code: DC4010
Housing: Thermoplastic PBT, UL94V-0
Impeller: Thermoplastic PBT, UL94V-0
Lead Wire: UL 1007 AWG#24
“+” Red,“-” Black
Optional wire: “Sensor” Yellow,“PWM” Blue
Operating Temperature: -10℃ to +70℃，35%-85%RH for Sleeve Type
-20℃ to +80℃，35%-85%RH for Ball Type
| Model | Rated Voltage | Operation Voltage | Power | Rated Current | Rated Speed | Air Flow | Air Pressure | Noise Level |
| V DC | V DC | W | A | RPM | CFM | MmH2O | dBA | |
| AM4010H5 | 5.0 | 4.5-5.5 | 1.00 | 0.20 | 7000 | 7.7 | 4.5 | 31 |
| AM4010M5 | 0.75 | 0.15 | 6000 | 6.6 | 3.3 | 27 | ||
| AM4010L5 | 0.65 | 0.13 | 5000 | 5.5 | 2.3 | 23 | ||
| AM4010H12 | 12.0 | 6.0-13.8 | 1.20 | 0.10 | 7000 | 7.7 | 4.5 | 31 |
| AM4010M12 | 0.96 | 0.08 | 6000 | 6.6 | 3.3 | 27 | ||
| AM4010L12 | 0.72 | 0.06 | 5000 | 5.5 | 2.3 | 23 | ||
| AM4010H24 | 24.0 | 12.0-27.6 | 2.16 | 0.09 | 7000 | 7.7 | 4.5 | 31 |
| AM4010M24 | 1.68 | 0.07 | 6000 | 6.6 | 3.3 | 27 | ||
| AM4010L24 | 1.20 | 0.05 | 5000 | 5.5 | 2.3 | 23 |
