DC 12038 Bi-Voltage

Size: 120*120*38mm
Motor: DC brushless fan motor
Bearing: Ball, Sleeve or Hydraulic
Weight: 280g
No. of Pole: 4 Poles
Rotating Direction: Counter-Clockwise
Optional Function: 1.Lock Protection
2.Auto restart
3.Waterproof Level
Technical characteristics

Item code: DC 12038 Bi-Voltage (Dual voltage)

Housing: Thermoplastic PBT, UL94V-0

Impeller: Thermoplastic PBT, UL94V-0

Lead Wire: UL 1007 AWG#24
                   “+” Red,“-” Black

Available Option: “Sensor” Yellow,“PWM” Blue

Operating Temperature: -20℃ to +80℃,35%-85%RH for Ball Type


Performance Parameter
Model Rated Voltage Operation Voltage Rated Current Rated Speed Air Flow Air Pressure Noise Level
V DC V DC A RPM CFM MmH2O dBA
AM12038BM1 12-24V 12V 0.15 1600 62.4 3.2 29
24V 0.24 2700 109.2 6.2 41
