AC 17251, round 172*51mm

Size: 172*51mm
Motor wires: 100% pure copper motor wires
Bearing: Ball or Sleeve
Weight: 740g
Safety: Impedance Protected

Technical characteristics

Item code: AC 17251

Housing: Aluminum Alloy, Painted Black

Impeller: Thermoplastic PBT, UL94V-0

Lead Wire: UL 1007 AWG#22

Termination: Lead wire, no connector

Operating Temperature: -10℃ to +70℃ for Sleeve Type
                                        -20℃ to +80℃ for Ball Type

Performance Parameter
Model Bearing System Rated Voltage Frequency Rated Current Rated Input Power Rated Speed Air Flow Air Pressure Noise Level
Ball Sleeve V AC Hz Amp Watt RPM CFM MmH2O dBA
AM17251MS1 110-125 50/60 0.30 34/32 2300/2500 155/170 7.5/9.07 45/49
AM17251MB1 110-125 50/60 0.50 37/36 2700/3100 190/230 16.0/17.8 45/49
AM17251MS2 200-240 50/60 0.18 34/32 2300/2500 155/170 7.5/9.07 45/49
AM17251MB2 200-240 50/60 0.22 35/32 2700/3100 190/230 16/17.8 45/49
AM17251MS3 380-420 50/60 0.13 38/36 2700/3000 190/230 16/17 45/50
AM17251MB3 380-420 50/60 0.13 38/36 2700/3700 190/230 16/17 45/50
