AC 150FZY Blue

Size: 160x160x60mm
Motor wires: 100% pure copper motor wires
Bearing: Ball
Weight: 1000g
Technical characteristics

Item code: AC 150FZY Blue

Housing: Iron or aluminium alloy, Painted Blue

Impeller: Thermoplastic PBT, UL94V-0

Lead Wire: UL 1007 AWG#22

Termination: Lead wire, no connector

Operating Temperature: -20℃ to +80℃ for Ball Type


Performance Parameter
Model Rated Voltage Frequency Rated Current Rated Input Power Rated Speed Air Flow Phase Number Noise Level
V  AC Hz Amp Watt RPM CFM dBA
AM150FZY-1 110-125 50/60 0.32 30 2500/2800 194/223 1 65/68
AM150FZY-2 200-240 50/60 0.15 30 2500/2800 194/223 1 65/68
AM150FZY-3 380-420 50/60 0.10 30 2500/2800 194/223 1 65/68
AM150FZY-3C 380-420 50/60 0.09 30 2500/2800 194/223 3 65/68
